200 KVA Pole Mounted Distribution Transformer

Baoding Zhongyi Electric Corporation is one of the leading manufacturers and suppliers of 200 kva pole mounted distribution transformer in China, featured by quality products and good price. Please rest assured to buy advanced 200 kva pole mounted distribution transformer for sale here from our factory.

200 kVA Pole Mounted Transformer Description:

Rated Power: 200kva

Rated Voltage: 11/0.4 kV

Rated Current: 10.5/288.68 A

Rated Frequency: 50 Hz

Number of Phase: 3 phase

Connection Symbol: Dyn11

Cooling Method: ONAN

Insulation Class: A

Insulation Level: LI75 AC28/ LIA

HV & LV winding material:Copper

Applied Standard: IEC 60076

Voltage Regulation: ±2 * 2.5%

Maximum Ambient Temperature: 50°C

Maximum Temperature Rise for oil: 50°C

Maximum Temperature Rise for winding: 55°C

No-load losses: 500W

Copper losses (at 75 °C): 2400W

Impedance Voltage (IEC Tolerance Applied): 4%

Transformer Type: Hermetically Sealed

Weight of oil: 160 kg

Total weight of transformer: 880 kg

Over all Dimensions (L x W x H): 1320 x 750 x 1170 mm

HV Bushing

LV Bushing

Tap Changer

Shipping

200 kVA Pole Mounted Transformer shipping 1

200 kVA Pole Mounted Transformer shipping 2
